Q45 NAMUR: Plastic Fiber Optic, Range: Depends on Fiber, Input: 5-15 V dc, Output: NAMUR, M12 Integral QD

Manufacturer's No: Q45AD9FPQ     Manufacturer: Turck Banner
Q45 NAMUR: Plastic Fiber Optic, Range: Depends on Fiber, Input: 5-15 V dc, Output: NAMUR, M12 Integral QD

Availability On Request

£182.38
  • Type: Photoelectric Sensor for Plastic Fibers
  • Connector: Male M12 × 1
  • Protection Class: IP67
  • Sensitivity Adjustment: Via Potentiometer
  • Operating Voltage: 5 to 15 VDC
  • NAMUR Output: Dark ? 1.2 mA ; Light ? 2.1 mA
  • Standards: EN 60947?5?6 (NAMUR), ATEX Category II 1 G
  • Ex Zone: 0


Product

Manufacturer Material ID -
Q45AD9FPQ
Net Weight -
0.26kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height amplifier -
102.6 Millimetre
Housing material -
Plastic
Length amplifier -
60.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
2.1 Milliampere
Switching frequency -
100 Hertz
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Other
Type of switching output -
NAMUR
Width amplifier -
44.5 Millimetre
Turck Banner

Availability On Request

£182.38
