3038668

Q45 Series: Plastic Fiber Optic, Range: Depends on Fiber, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, M12 Integral QD

Manufacturer's No: Q45BB6FPQ5     Manufacturer: Turck Banner
Q45 Series: Plastic Fiber Optic, Range: Depends on Fiber, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, M12 Integral QD

Availability On Request

POA
  • Type: Photoelectric Sensor for Plastic Fibers
  • Operating Voltage: 10 to 30 VDC
  • Connector: Male M12 × 1, Male Connector Eurofast
  • Protection Class: IP67
  • Switching Output: Bipolar
  • Operation: Light or dark, adjusted via switch


Product

Manufacturer Material ID -
Q45BB6FPQ5
Net Weight -
0.25kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height amplifier -
102.6 Millimetre
Housing material -
Plastic
Length amplifier -
60.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
50 Milliampere
Switching frequency -
250 Hertz
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Width amplifier -
44.5 Millimetre
Turck Banner

Availability On Request

POA
