3037011

Q45 Series: Diffuse, Range: 450, Input: 90-250 V ac, Output: SPST Solid-state Relay, 3-pin Mini Integral QD

Manufacturer's No: Q45BW22DQ     Manufacturer: Turck Banner
Q45 Series: Diffuse, Range: 450, Input: 90-250 V ac, Output: SPST Solid-state Relay, 3-pin Mini Integral QD

Availability On Request

£172.40
  • Photoelectric sensor in diffuse mode
  • Operating voltage: 90-250 VAC
  • Maximum range: 450 mm
  • Male connector: 7/8"
  • Protection class: IP67
  • Sensitivity adjustment via potentiometer
  • Relay output: NO (SPST)
  • Light or dark operation selectable via selector switch


Product

Manufacturer Material ID -
Q45BW22DQ
Net Weight -
0.25kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
30 Millimetre
Height of sensor -
101.6 Millimetre
Housing material -
Plastic
Length of sensor -
56.4 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
450 Millimetre
Reaction time -
2 Millisecond
Type of electric connection -
Connector 7/8 inch
Type of light -
Infrared light
Type of switch function -
Normally open contact (NO)
Type of switching output -
Relay contact
Wavelength of the sensor -
880 Nanometre
Width sensor -
44.5 Millimetre
Turck Banner

Availability On Request

£172.40
