3035445

Q45 Series: Plastic Fiber Optic, Range: Depends on Fiber, Input: 90-250 V ac, Output: SPDT Electromechanical Relay, 2 m (6.5 ft) C

Manufacturer's No: Q45VR2FP     Manufacturer: Turck Banner
Q45 Series: Plastic Fiber Optic, Range: Depends on Fiber, Input: 90-250 V ac, Output: SPDT Electromechanical Relay, 2 m (6.5 ft) Cable

Availability On Request

£163.32
  • Type: Photoelectric Sensor for Plastic Fibers
  • Operating Voltage: 90-250 VAC
  • Cable Length: 2 meters, PVC material
  • Protection Class: IP67
  • Sensitivity Adjustment: Via potentiometer
  • Output: Relay, changeover (SPDT)
  • Operation Mode: Light or dark, adjustable via selector switch
  • Adapter Set PFK-B for connecting plastic optical fibers available separately


Product

Manufacturer Material ID -
Q45VR2FP
Net Weight -
0.03kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height amplifier -
87.6 Millimetre
Housing material -
Plastic
Length amplifier -
60.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
50 Milliampere
Type of electric connection -
Cable
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
Relay contact
Width amplifier -
44.5 Millimetre
Turck Banner

Availability On Request

£163.32
