3037005

Q45 Series: Infrared Glass Fiber Optic, Range: Depends on Fiber, Input: 90-250 V ac, Output: SPDT Electromechanical Relay, 5-pin M

Manufacturer's No: Q45VR2FQ     Manufacturer: Turck Banner
Q45 Series: Infrared Glass Fiber Optic, Range: Depends on Fiber, Input: 90-250 V ac, Output: SPDT Electromechanical Relay, 5-pin Mini Integral QD

Availability On Request

£141.55
  • Photoelectric sensor for glass fibers
  • Operating voltage: 90-250 VAC
  • Male connector: 7/8"
  • Protection class: IP67
  • Sensitivity adjusted via potentiometer
  • Relay output: changeover (SPDT)
  • Light or dark operation selectable via selector switch


Product

Manufacturer Material ID -
Q45VR2FQ
Net Weight -
0.27kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height amplifier -
101.6 Millimetre
Housing material -
Plastic
Length amplifier -
60.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
50 Milliampere
Type of electric connection -
Connector 7/8 inch
Type of light -
Infrared light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
Relay contact
Width amplifier -
44.5 Millimetre
Turck Banner

Availability On Request

£141.55
