3097341

Q4X Series: Laser Adjustable Field, Range: 310, Input: 10-30 V dc, Output: 1 PNP/NPN with IO-Link Communication, 1 PNP, 4-pin M12

Manufacturer's No: Q4XFKLAF310-Q8     Manufacturer: Turck Banner
Q4X Series: Laser Adjustable Field, Range: 310, Input: 10-30 V dc, Output: 1 PNP/NPN with IO-Link Communication, 1 PNP, 4-pin M12 Integral QD, Flush Mount Housing

Availability On Request

£451.87
  • Photoelectric Sensor with Laser Distance Sensor (Triangulation)
  • Operating voltage: 10-30 VDC
  • Max. range: 310 mm
  • 4-digit 7-segment LED display
  • Output: Push/pull switching output with IO-Link communication
  • Additional output: PNP switching output
  • Features 3 buttons for control
  • Output indicator: Yellow
  • IP67/69K and ECOLAB-certified for durability
  • Laser class 1, red, 655 nm

Read more

  • Range: 35-310 mm
  • Rectangular design with stainless steel housing (1.4404)
  • Functions include teach-in input, laser control, synchronization, and Pulse Frequency Modulation (PFM)
  • Transmission of process value and parameterization via IO-Link


Product

Manufacturer Material ID -
Q4XFKLAF310-Q8
Net Weight -
0.14kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
43211902

Technical Specification

Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
57.5 Millimetre
Housing material -
Other
Laser protection class -
Class 1
Length of sensor -
33.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Other
Standard for interfaces -
Other
Supply voltage -
10 Volt
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Width sensor -
18 Millimetre
Turck Banner

Availability On Request

£451.87
