3071744

Q60 Series: Adjust-Field Laser (Cls 1) Univ Volt, Range: 200-1400, Input: 12-250 V dc or 24-250 V ac, Output: Electromechanical Re

Manufacturer's No: Q60VR3LAF1400Q1     Manufacturer: Turck Banner
Q60 Series: Adjust-Field Laser (Cls 1) Univ Volt, Range: 200-1400, Input: 12-250 V dc or 24-250 V ac, Output: Electromechanical Relay (SPST), Micro-Style QD

Availability On Request

£422.83
  • Type: Photoelectric Sensor, Laser Sensor, Diffuse Mode
  • Adjustable Background Suppression
  • Max. Range: 1400 mm
  • Operating Voltage: 24-250 VAC / 12-250 VDC
  • Cable Length: 0.15 m
  • Connector: Male 1/2", 4-pin, rotatable by 90°
  • Protection Class: IP67
  • Features: 5-segment LED display, Signal indication, Keylock
  • Switch ON/OFF Delay: Adjustable between 8-16 ms
  • Relay Output


Product

Manufacturer Material ID -
Q60VR3LAF1400Q1
Net Weight -
0.15kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Adjustment range -
200 Millimetre
Ambient temperature -
-10 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
75 Millimetre
Housing material -
Plastic
Laser protection class -
Class 1
Length of sensor -
60 Millimetre
Material of cable sheath -
Polyurethane (PUR)
Material of optical surface -
Plastic
Max. switching distance -
1400 Millimetre
Rated switching distance -
1400 Millimetre
Reaction time -
15 Millisecond
Switching frequency -
33 Hertz
Type of electric connection -
Connector 7/8 inch
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
Relay contact
Wavelength of the sensor -
650 Nanometre
Width sensor -
25 Millimetre
Turck Banner

Availability On Request

£422.83
