3049232

QMT42 Series: Fixed Field, Range: 1000, Input: 10-30 V dc, Output: SPDT (Complementary) NPN, 4-pin M12 Integral QD

Manufacturer's No: QMT42VN6FF1000Q     Manufacturer: Turck Banner
QMT42 Series: Fixed Field, Range: 1000, Input: 10-30 V dc, Output: SPDT (Complementary) NPN, 4-pin M12 Integral QD

Availability On Request

£258.60
  • Photoelectric sensor in diffuse mode
  • Features fixed-field background suppression
  • Operating voltage: 10-30 VDC
  • Maximum range: 1000 mm
  • Male M12 × 1, 4-pin connection
  • Metal housing (ZN, black)
  • Protection class: IP67
  • NPN switching output
  • Light/dark operation


Product

Manufacturer Material ID -
QMT42VN6FF1000Q
Net Weight -
0.14kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Adjustment range -
50 Millimetre
Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
76.2 Millimetre
Housing material -
Metal
Length of sensor -
42 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
1000 Millimetre
Rated switching distance -
1000 Millimetre
Reaction time -
1 Millisecond
Switching frequency -
500 Hertz
Type of electric connection -
Connector M12
Type of light -
Infrared light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
NPN
Wavelength of the sensor -
880 Nanometre
Width sensor -
18 Millimetre
Turck Banner

Availability On Request

£258.60
