3048944

Photoelectric Sensor, Diffuse Mode Sensor with Adjustable Background Suppression

Manufacturer's No: QMT42VP6AFV400 W/30     Manufacturer: Turck Banner
Photoelectric Sensor, Diffuse Mode Sensor with Adjustable Background Suppression

Availability Available to order

POA
  • Photoelectric sensor in diffuse mode
  • Adjustable background suppression
  • Operating voltage: 10-30 VDC
  • Maximum range: 400 mm
  • Cable length: 9 m, PVC material
  • 4-wire cable, 2 m long
  • Metal housing in black ZN
  • Protection class: IP67
  • Scanning width adjusted via potentiometer
  • PNP switching output for light/dark operation


Product

Manufacturer Material ID -
QMT42VP6AFV400 W/30
Net Weight -
0.24kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Adjustment range -
125 Millimetre
Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
58 Millimetre
Housing material -
Metal
Length of sensor -
42 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
400 Millimetre
Rated switching distance -
400 Millimetre
Reaction time -
1 Millisecond
Switching frequency -
500 Hertz
Type of electric connection -
Cable
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Wavelength of the sensor -
680 Nanometre
Width sensor -
18 Millimetre
