3079166

WORLD-BEAM QS30 Series: H2O HP Emitter, Range: 4 m, Input: 10-30 V dc, Output: Not Applicable, 150 (6 in) 5-pin M12 Pigtail QD

Manufacturer's No: QS30EXH2OQ5     Manufacturer: Turck Banner
WORLD-BEAM QS30 Series: H2O HP Emitter, Range: 4 m, Input: 10-30 V dc, Output: Not Applicable, 150 (6 in) 5-pin M12 Pigtail QD

Availability On Request

POA
  • Photoelectric sensor for water detection
  • Opposed mode sensor (Emitter)
  • Operating voltage: 10-30 VDC
  • Max. range: 4000 mm
  • Cable length: 0.15 m
  • Male M12 × 1, 5-pin
  • Protection class: IP67
  • LED all-round visible
  • Selectable operating frequency
  • Protection against crosstalk

Read more

  • Emitter LED switchable


Product

Manufacturer Material ID -
QS30EXH2OQ5
Net Weight -
0.11kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39121527

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
30 Millimetre
Height of sensor -
57 Millimetre
Housing material -
Plastic
Length of sensor -
51.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
4000 Millimetre
Rated switching distance -
4000 Millimetre
Reaction time -
1 Millisecond
Setting procedure -
Other
Type of electric connection -
Connector M12
Type of light -
Infrared light
Wavelength of the sensor -
1450 Nanometre
Width sensor -
22 Millimetre
Turck Banner

Availability On Request

POA
