3002726

QT50U Analog Series: Proximity Mode, Range: 200 - 8 m, Input: 10-30 V dc, Outputs: Analog: 0-10 V or 4-20 mA, 2 m (6.5 ft) Cable

Manufacturer's No: QT50ULB     Manufacturer: Turck Banner
QT50U Analog Series: Proximity Mode, Range: 200 - 8 m, Input: 10-30 V dc, Outputs: Analog: 0-10 V or 4-20 mA, 2 m (6.5 ft) Cable

Availability On Request

£836.59
  • Type: Ultrasonic Sensor (diffuse mode)
  • Output: Analog
  • Operating Voltage: 10-30 VDC
  • Max. Range: 8000 mm
  • Cable Length: 2 m, 5-wire PVC
  • LED indicator for signal intensity
  • Temperature compensation selectable via DIP switch
  • Output selectable: Current or voltage via DIP switch
  • Response Time: 100-2300 ms, adjustable via DIP switch
  • Blind Zone: 20 cm

Read more

  • Range: 800 cm


Product

Manufacturer Material ID -
QT50ULB
Net Weight -
0.62kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Height of sensor -
84.2 Millimetre
Housing material -
Plastic
Length of sensor -
67.4 Millimetre
Material active area of sensor -
Plastic
Material of cable sheath -
Polyvinyl chloride (PVC)
Measuring range length -
200 Millimetre
Supply voltage -
10 Volt
Type of analogy output -
4 mA ... 20 mA
Type of electric connection -
Cable
Type of switching output -
Other
Width sensor -
74 Millimetre
Turck Banner

Availability On Request

£836.59
