1590856 {T}

Inductive Angle Sensor, With Analog Output For Use in Vehicle Board Nets, Premiu

Manufacturer's No: RI360P1-QR14-ELU4X2-0.3-RS5/S97     Manufacturer: Turck Banner
Inductive Angle Sensor, With Analog Output For Use in Vehicle Board Nets, Premiu

Availability Available to order

£209.80
  • Inductive Angle Sensor with Analog Output
  • Premium Line for Vehicle Board Nets
  • Operating Voltage: 8-30 VDC
  • Cable Length: 0.3 m
  • Rectangular plastic design with multiple mounting options
  • Included P1-Ri-QR14
  • Suitable for vehicle board nets at 12V and 24V
  • Increased interference immunity up to 30V/m
  • Immune to conducted interference according to DIN ISO 7637-2 (SAE J 113-11)
  • Extended temperature range

Read more

  • High protection class IP68/IP69K
  • Protection against salt spray and rapid temperature changes
  • Measuring range displayed via LED
  • Immune to electromagnetic interference
  • Resolution: 12-bit
  • Analog output with programmable measuring range of 0.5-4.5 V
  • Cable with connector


Product

Manufacturer Material ID -
RI360P1-QR14-ELU4X2-0.3-RS5/S97
Net Weight -
0.08kg

Additional Product Information

Commodity Code -
90318020000
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Degree of protection (IP rating) -
IP68
Diameter axle -
6 Millimetre
Housing material -
Plastic
Model -
Other
Physical measurement principle -
Inductive
Programmable -
Standard for interfaces -
Analogue
Type of electric connection -
Cable with connector
Type of shaft encoder -
Hollow shaft
Turck Banner

Availability Available to order

£209.80
