63000106

The Safety switch from . Contact allocation: 2NC + 1NO, Slow-action contact; Connection: Connector, M12, Plastic, 8 -pin; Dimensio

Manufacturer's No: S20-P4C1-M12-FH     Manufacturer: Leuze
The Safety switch from . Contact allocation: 2NC + 1NO, Slow-action contact; Connection: Connector, M12, Plastic, 8 -pin; Dimensions: 30,8 mm x 30,8 mm x 93 mm; Housing material: Plastic, Glass fibe

Availability Back Order

£64.00
  • Contact allocation: 2NC + 1NO, Slow-action contact
  • Switch type: Interlock device without guard interlocking, ISO 14119
  • Dimensions: 30.8 mm x 30.8 mm x 93 mm
  • Housing material: Plastic, Glass fiber reinforced (PPS), self-extinguishing
  • Connection: Connector, M12, 8-pin
  • Approach actuation directions: 1 x top, 4 x side (90°)
  • Actuation force (pull-out): 10 N
  • Degree of protection: IP 67
  • Certifications: IMQ, c UL US

Accessories

Others



Product

Manufacturer Material ID -
S20-P4C1-M12-FH
Net Weight -
0.10kg

Additional Product Information

Commodity Code -
85369095
Country of Origin -
IT
UNSPSC -
39122200

Technical Specification

Rated operation current Ie at AC-15, 230 V -
- Ampere
Rated operation current Ie at DC-13, 230 V -
- Ampere
Type of interface -
UN
Rated operation current Ie at AC-15, 125 V -
- Ampere
Rated operation current Ie at AC-15, 24 V -
- Ampere
Rated operation current Ie at DC-13, 125 V -
- Ampere
Rated operation current Ie at DC-13, 24 V -
- Ampere
Number of contacts as normally closed contact -
-
Number of contacts as normally open contact -
-
Number of contacts as change-over contact -
-
Degree of protection (NEMA) -
UN
Material housing -
Plastic
Degree of protection (IP) -
IP67
Thumbnail of product picture -
Ambient temperature during operating -
-25 Degrees celsius
Coating housing -
Other
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Height of sensor -
30.8 Millimetre
Housing material -
Plastic
Interface type -
None
Length of sensor -
93 Millimetre
Number of safety auxiliary contacts -
0
Suitable for safety functions -
Type of electric connection -
Connector M12
Type of interface for safety communication -
None
Type of switching contact -
Slow-action switch
Width sensor -
30.8 Millimetre
Leuze

Availability Back Order

£64.00
