3055474

SLE30 EXPERT Series: Teach Mode Slot Sensor; Slot width: 30 mm; Input: 1030V dc; Output: Bipolar: 1 NPN; 1 PNP; 2 m 6.5 ft Cable;

Manufacturer's No: SLE30B6V
SLE30 EXPERT Series: Teach Mode Slot Sensor; Slot width: 30 mm; Input: 1030V dc; Output: Bipolar: 1 NPN; 1 PNP; 2 m 6.5 ft Cable;

Availability Back Order

£243.93
  • SLE30 EXPERT Series Teach Mode Slot Sensor
  • Slot width: 30 mm
  • Input: 10-30V dc
  • Output: 1 NPN, 1 PNP
  • Cable length: 2 meters (6.5 feet)


Product

Manufacturer Material ID -
SLE30B6V
Net Weight -

Additional Product Information

UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Special construction
Degree of protection (IP rating) -
IP67
Fork width -
30 Millimetre
Height of sensor -
52 Millimetre
Housing material -
Plastic
Length of sensor -
72 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
30 Millimetre
Rated switching distance -
30 Millimetre
Reaction time -
0.5 Millisecond
Type of electric connection -
Cable
Type of light -
Polarity free red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Wavelength of the sensor -
680 Nanometre
Width sensor -
18.8 Millimetre


Availability Back Order

£243.93
