MINI-BEAM: Diffuse, Range: 380, Input: 24-240 V ac, Output: SPST Solid-state 2-Wire, 3-pin Micro Integral QD

Manufacturer's No: SM2A312DQD     Manufacturer: Turck Banner
MINI-BEAM: Diffuse, Range: 380, Input: 24-240 V ac, Output: SPST Solid-state 2-Wire, 3-pin Micro Integral QD

Availability On Request

£179.66
  • Photoelectric sensor in diffuse mode
  • Operating voltage: 24-240 VAC
  • Max. range: 380 mm
  • 1/2" connector
  • Protection class: IP67
  • Sensitivity adjustable via potentiometer
  • Alignment indicator
  • Switching output: bipolar
  • Light/dark operation


Product

Manufacturer Material ID -
SM2A312DQD
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
30.7 Millimetre
Housing material -
Plastic
Length of sensor -
84 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
380 Millimetre
Reaction time -
8 Millisecond
Setting procedure -
Other
Type of electric connection -
Connector 1/2 inch
Type of light -
Infrared light
Type of switching output -
Relay contact
Wavelength of the sensor -
650 Nanometre
Width sensor -
12.2 Millimetre
