MINI-BEAM: Infrared 880 nm Glass Fiber Optic, Range: Depends on Fiber, Input: 24-240 V ac, Output: SPST Solid-state 2-Wire, 3-pin

Manufacturer's No: SM2A312FQD     Manufacturer: Turck Banner
MINI-BEAM: Infrared 880 nm Glass Fiber Optic, Range: Depends on Fiber, Input: 24-240 V ac, Output: SPST Solid-state 2-Wire, 3-pin Micro Integral QD

Availability On Request

£179.66
  • Photoelectric sensor for glass fibers
  • Operating voltage: 24-240 VAC
  • 1/2" connector
  • Protection class: IP67
  • Sensitivity adjusted via potentiometer
  • Alignment indicator
  • Switching output: bipolar
  • Light/dark operation


Product

Manufacturer Material ID -
SM2A312FQD
Net Weight -
0.08kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height amplifier -
30.7 Millimetre
Housing material -
Plastic
Length amplifier -
87.9 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Type of electric connection -
Connector 1/2 inch
Type of light -
Infrared light
Type of switching output -
Relay contact
Width amplifier -
12.2 Millimetre
Turck Banner

Availability On Request

£179.66
