SM312DM5 V MINIBEAM SCANNER

Manufacturer's No: SM312DM5V     Manufacturer: Turck Banner
SM312DM5 V MINIBEAM SCANNER

Availability On Request

£290.36
  • Photoelectric Sensor
  • Type: Diffuse Mode Sensor
  • Operating Voltage: 5 to 30 VDC
  • Max. Range: 380 mm
  • Cable Length: 2 m, PVC
  • Protection Class: IP67
  • Special Type: 5 V
  • Outputs: 1 x NPN
  • Sensitivity Adjustable via Potentiometer
  • Alignment Indicator

Read more

  • Light/Dark Operation


Product

Manufacturer Material ID -
SM312DM5V
Net Weight -
0.16kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
30.7 Millimetre
Housing material -
Plastic
Length of sensor -
53.3 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
380 Millimetre
Reaction time -
1 Millisecond
Switching frequency -
500 Hertz
Type of electric connection -
Cable
Type of light -
Infrared light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Wavelength of the sensor -
880 Nanometre
Width sensor -
12.3 Millimetre
Turck Banner

Availability On Request

£290.36
