MINI-BEAM EXPERT: Infrared 880 nm Glass Fiber Optic, Range: Depends on Fiber, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, 4-

Manufacturer's No: SME312FQD     Manufacturer: Turck Banner
MINI-BEAM EXPERT: Infrared 880 nm Glass Fiber Optic, Range: Depends on Fiber, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, 4-pin M12 Integral QD

Availability On Request

POA
  • Photoelectric sensor for glass fibers
  • Operating voltage: 10-30 VDC
  • Male M12 x 1, 5-pin connector
  • Protection class IP67
  • Teach-in function
  • Switching output: bipolar
  • Light/dark operation


Product

Manufacturer Material ID -
SME312FQD
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39121527

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height amplifier -
30.7 Millimetre
Housing material -
Plastic
Length amplifier -
84 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
45 Milliampere
Type of electric connection -
Connector M12
Type of light -
Infrared light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Width amplifier -
12.3 Millimetre
Turck Banner

Availability On Request

POA
