1007700

Inductive Sensor, Slot-type

Manufacturer's No: SI2-K08-Y1     Manufacturer: Turck Banner
Inductive Sensor, Slot-type

Availability On Request

£50.10
  • Inductive slot-type sensor
  • Cable length: 0.21 m
  • Slot sensor height: 8 mm
  • Material: Plastic (polypropylene)
  • Mechanical end stop, removable
  • Suitable for analog pointer instruments
  • DC 2-wire, nominal 8.2 VDC
  • Output according to DIN EN 60947-5-6 (NAMUR)
  • Strand connection, mostly jacketed
  • ATEX category II 1 G, Ex zone 0

Read more

  • ATEX category II 1 D, Ex zone 20
  • SIL2 (Low Demand Mode) according to IEC 61508, PL c according to ISO 13849-1 with HFT0
  • SIL3 (All Demand Mode) according to IEC 61508, PL e according to ISO 13849-1 with redundant configuration HFT1


Product

Manufacturer Material ID -
SI2-K08-Y1
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
CH
UNSPSC -
39122216

Technical Specification

Construction type housing -
Special construction
Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 1G
Height of sensor -
8 Millimetre
Housing material -
Plastic
Length of sensor -
11 Millimetre
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
None
Switching frequency -
2500 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Other
Type of switching output -
NAMUR
Voltage type -
DC
Width sensor -
15 Millimetre
