3034922

EZ-BEAM T18 Series: Diffuse, Range: 300, Input: 20-250 V ac, Light Operate, 2 m (6.5 ft) Cable

Manufacturer's No: T18AW3D     Manufacturer: Turck Banner
EZ-BEAM T18 Series: Diffuse, Range: 300, Input: 20-250 V ac, Light Operate, 2 m (6.5 ft) Cable

Availability On Request

£111.61
  • Photoelectric Sensor
  • Diffuse Mode Sensor
  • Operating Voltage: 20-250 VAC
  • Max. Range: 300 mm
  • Cable Length: 2 m
  • Protection Class: IP67
  • Ambient Temperature: -40 to +70 °C
  • Selectable light/dark operation
  • Light operation with alarm function


Product

Manufacturer Material ID -
T18AW3D
Net Weight -
0.16kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
41.5 Millimetre
Housing material -
Plastic
Length of sensor -
30 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
300 Millimetre
Reaction time -
16 Millisecond
Sensing mode -
Light switching
Setting procedure -
Other
Switching frequency -
40 Hertz
Type of electric connection -
Cable
Type of light -
Infrared light
Type of switch function -
Other
Type of switching output -
Relay contact
Wavelength of the sensor -
880 Nanometre
Width sensor -
30 Millimetre
Turck Banner

Availability On Request

£111.61
