TM18 VP6DVQ8 EZ BEAM TM18: Diffuse (Red), Range: 500, Input: 10-30 V dc, Outputs: PNP Complementary, 4-pin M12 Integral QD

Manufacturer's No: TM18VP6DVQ8     Manufacturer: Turck Banner
TM18 VP6DVQ8 EZ BEAM TM18: Diffuse (Red), Range: 500, Input: 10-30 V dc, Outputs: PNP Complementary, 4-pin M12 Integral QD

Availability On Request

£107.98
  • Type: Photoelectric Sensor, Diffuse Mode
  • Operating Voltage: 10-30 VDC
  • Max. Range: 500 mm
  • Connector: M12 × 1 male, 4-pin
  • Protection Classes: IP67/IP69K
  • Ambient Temperature: -40°C to +70°C
  • Housing Material: Metal
  • Switching Output: PNP
  • Operation: Light and Dark
  • Unique Feature: Wide operating temperature range of -40°C to +70°C


Product

Manufacturer Material ID -
TM18VP6DVQ8
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
49 Millimetre
Housing material -
Metal
Length of sensor -
30 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
500 Millimetre
Reaction time -
3 Millisecond
Setting procedure -
Other
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Wavelength of the sensor -
880 Nanometre
Width sensor -
30 Millimetre
Turck Banner

Availability On Request

£107.98
