MS6-LF-1/2-CUV Filter

Manufacturer's No: MS6-LF-1/2-CUV     Manufacturer: Festo
MS6-LF-1/2-CUV Filter

Availability Available to order

£113.65
  • Filter Model: MS6-LF-1/2-CUV
  • Size: 6
  • Series: MS
  • Grade of Filtration: 5 µm
  • Mounting Position: Vertical +/- 5°
  • Condensate Drain: Fully automatic
  • Design: Sintered filter with centrifugal separator
  • Bowl Guard: Integrated metal bowl
  • Degree of Condensate Separation: 75%
  • Operating Pressure: 2 BAR to 12 BAR

Read more

  • Standard Nominal Flow Rate: 3200 L/min
  • Operating Medium: Compressed air to ISO 8573-1:2010 [7:9:-] and inert gases
  • Corrosion Resistance Class: CRC 2 - Moderate corrosion stress
  • LABS (PWIS) Conformity: VDMA24364-B1/B2-L
  • Storage Temperature: -10°C to 60°C
  • Air Purity Class at Output: Compressed air to ISO 8573-1:2010 [6:8:4]
  • Media Temperature: -10°C to 60°C
  • Ambient Temperature: -10°C to 60°C
  • Pore Size: 5 µm
  • Product Weight: 820 g
  • Type of Mounting: In-line installation with accessories
  • Pneumatic Connection Port 1: G1/2
  • Pneumatic Connection Port 2: G1/2
  • Material Seals: NBR
  • Material Filter: PE
  • Material Housing: Die-cast aluminium
  • Material Bowl: Wrought aluminium alloy
  • Material Separating Plate: POM
  • RoHS-compliant materials

Accessories



Product

Manufacturer Material ID -
MS6-LF-1/2-CUV
Net Weight -
0.93kg

Additional Product Information

Commodity Code -
70099200
Country of Origin -
DE
UNSPSC -
39121528

Technical Specification

Width -
- Millimetre
Outer diameter -
- Millimetre
Height -
- Millimetre
Number of mounting holes -
-
Thumbnail of product picture -
Shape -
Other
Festo

Availability Available to order

£113.65
