3055404

VS2 Series: Receiver, Range: 1.2 m max, Input: 12-24 V dc, Output: Complementary PNP Light Operate, 2 m (6.5 ft) Cable

Manufacturer's No: VS2AP5R     Manufacturer: Turck Banner
VS2 Series: Receiver, Range: 1.2 m max, Input: 12-24 V dc, Output: Complementary PNP Light Operate, 2 m (6.5 ft) Cable

Availability On Request

£86.20
  • Type: Photoelectric Sensor (Opposed Mode Receiver)
  • Miniature sensor with ultra flat design
  • Operating Voltage: 10-30 VDC
  • Max. Range: 3000 mm
  • Cable Length: 2 m
  • Output: PNP switching
  • Light operation


Product

Manufacturer Material ID -
VS2AP5R
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
25.1 Millimetre
Housing material -
Plastic
Length of sensor -
4.7 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
3000 Millimetre
Rated switching distance -
3000 Millimetre
Reaction time -
1 Millisecond
Sensing mode -
Light switching
Switching frequency -
500 Hertz
Type of electric connection -
Cable
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP
Wavelength of the sensor -
940 Nanometre
Width sensor -
12 Millimetre
Turck Banner

Availability On Request

£86.20
