787-1201

Switched-mode power supply, Compact, 1-phase,

Manufacturer's No: 787-1201     Manufacturer: WAGO
Switched-mode power supply, Compact, 1-phase,

Availability Back Order

£41.344
List Price £51.68
  • Switched-mode power supply
  • Compact design
  • 1-phase
  • 12 VDC output voltage
  • 2.5 A output current
  • DC-OK LED indicator

Accessories

Gripping Plate, 3- To 4-Pole Suitable For 5 mm Pin Spacing Light Gray

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 2092-1601
Price £0.10
Back Order


Product

Manufacturer Material ID -
787-1201
Net Weight -
0.32kg

Additional Product Information

Commodity Code -
85044083
Country of Origin -
CN
UNSPSC -
32121704

Technical Specification

Built-in height -
- Millimetre
Power consumption -
- Voltampere
Built-in width -
- Millimetre
2nd secondary output voltage -
- Volt
3rd secondary output voltage -
- Volt
Performance level acc. EN ISO 13849-1 -
UN
Max. output current 2 -
- Ampere
Max. output current 3 -
- Ampere
Nominal value output voltage 2 -
- Volt
Nominal value output voltage 3 -
- Volt
Nominal value output current 2 -
- Ampere
Nominal value output current 3 -
- Ampere
SIL according to IEC 61508 -
UN
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP20
1st secondary output voltage -
10 Volt
Degree of protection (IP rating) -
IP20
Depth -
56 Millimetre
Height -
90 Millimetre
Max. output current 1 -
2.5 Ampere
Modular version -
Nominal value output current 1 -
2.5 Ampere
Nominal value output voltage 1 -
12 Volt
Output voltage stabilized -
Power output -
30 Watt
Rail mounting possible -
Rated supply voltage at AC 50 Hz -
90 Volt
Rated supply voltage at AC 60 Hz -
90 Volt
Rated supply voltage at DC -
125 Volt
Secondary voltage adjustable -
Short-circuit-proof -
Stabilized -
Type of electric connection -
Spring clamp connection
Voltage type of supply voltage -
AC/DC
Wall mounting possible -
Width -
54 Millimetre
Width in number of modular spacings -
3

Availability Back Order

£41.344
List Price £51.68
