NPQM-L-G12-Q14-P10 Push-in L-fitting

Manufacturer's No: NPQM-L-G12-Q14-P10     Manufacturer: Festo
NPQM-L-G12-Q14-P10 Push-in L-fitting

Availability On Request

£11.06
  • Push-in L-fitting for tubing O.D. 14mm
  • Metal design with external hexagon
  • Male thread G1/2
  • Operating pressure range: -0.095 MPa to 1.6 MPa (-0.95 bar to 16 bar)
  • Operating temperature range: -20°C to 70°C
  • Nominal torque: 9 Nm
  • Corrosion resistance class CRC: 1 (Low corrosion stress)
  • LABS (PWIS) conformity: VDMA24364-B1/B2-L
  • Material: Brass housing, nickel-plated; NBR tubing seal
  • Package quantity: 10 pieces

Read more

  • Product weight: 69.9g
  • Size: Standard, Nominal size: 11mm
  • Type of seal on screwed plug: Sealing ring
  • Design: L-shape with push-pull principle
  • Type of mounting: External hexagon, A/F 20mm
  • Pneumatic connection: Male thread G1/2 for port 1, 14mm tubing for port 2
  • Operating medium: Compressed air to ISO 8573-1:2010 [7:-:-]
  • Note on operating and pilot medium: Lubricated operation possible
  • Tolerance for nominal tightening torque: ±20%
  • Note on materials: RoHS-compliant


Product

Manufacturer Material ID -
NPQM-L-G12-Q14-P10
Net Weight -
0.07kg

Additional Product Information

Commodity Code -
85389099
Country of Origin -
CH
UNSPSC -
39121501

Technical Specification

Thumbnail of product picture -
Medien_800/Pictures_800/570461_800.jpg
Accessory -
Type of accessory/spare part -
Other
