DGSL-25-20-EA Mini slide

Manufacturer's No: DGSL-25-20-EA     Manufacturer: Festo
DGSL-25-20-EA Mini slide

Availability Available to order

£10.46
  • Mini slide with a stroke of 20mm
  • Adjustable end position range: Front 11.5mm, Rear 5.5mm
  • Piston diameter: 32mm
  • Operating mode: Yoke drive unit
  • Cushioning: Short elastic cushioning rings/pads at both ends
  • Guide: Ball bearing cage guide
  • Position detection: Via proximity switch
  • Operating pressure: 0.1MPa, 0.8MPa, 1 bar, 8 bar
  • Max. speed: 0.8m/s
  • Repetition accuracy: 0.3mm

Read more

  • Mode of operation: Double-acting
  • Operating medium: Compressed air to ISO 8573-1:2010 [7:4:4]
  • Corrosion resistance class CRC: 0 - No corrosion stress
  • LABS (PWIS) conformity: VDMA24364-B1/B2-L
  • Cleanroom class: Class 7 according to ISO 14644-1
  • Ambient temperature: 0°C to 60°C
  • Impact energy in end positions: 0.55Nm
  • Cushioning length: 1.3mm
  • Max. force: Fy 3744N, Fz 3744N
  • Max. moment: Mx 100Nm, My 60Nm, Mz 60Nm
  • Theoretical force at 0.6MPa (6 bar, 87 psi): Return stroke 415N, Advance stroke 483N
  • Moving mass: 1052g
  • Product weight: 2750g
  • Type of mounting: With through-hole
  • Pneumatic connection: G1/8
  • Material: Cover - Wrought aluminium alloy, Seals - HNBR, Housing - Wrought aluminium alloy, Piston rod - High-alloy stainless steel
  • RoHS-compliant materials
  • Note: Lubricated operation possible, alternative connections in product drawing.

Accessories



Product

Manufacturer Material ID -
DGSL-25-20-EA
Net Weight -
0.03kg

Additional Product Information

Commodity Code -
85389099
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
32151705
