DGSL-25-30-EA Mini slide

Manufacturer's No: DGSL-25-30-EA     Manufacturer: Festo
DGSL-25-30-EA Mini slide

Availability Available to order

£45.01
  • Model: DGSL-25-30-EA Mini slide
  • Stroke: 30mm
  • Piston Diameter: 32mm
  • Adjustable End Position Range/Length Front: 11.5mm
  • Adjustable End Position Range/Length Rear: 5.5mm
  • Operating Pressure: 0.1 MPa, 0.8 MPa, 1 bar, 8 bar
  • Max. Speed: 0.8 m/s
  • Repetition Accuracy: 0.3mm
  • Operating Mode: Double-acting
  • Cushioning: Short elastic cushioning rings/pads at both ends

Read more

  • Guide: Ball bearing cage guide
  • Position Detection: Via proximity switch
  • Operating Medium: Compressed air to ISO 8573-1:2010 [7:4:4]
  • Lubrication: Lubricated operation possible
  • Corrosion Resistance Class CRC: 0 - No corrosion stress
  • LABS (PWIS) Conformity: VDMA24364-B1/B2-L
  • Cleanroom Class: Class 7 according to ISO 14644-1
  • Ambient Temperature: 0°C to 60°C
  • Impact Energy in End Positions: 0.55 Nm
  • Cushioning Length: 1.3mm
  • Max. Force Fy: 4205N
  • Max. Force Fz: 4205N
  • Max. Moment Mx: 100Nm
  • Max. Moment My: 60Nm
  • Max. Moment Mz: 60Nm
  • Theoretical Force at 0.6 MPa (6 bar, 87 psi), Return Stroke: 415N
  • Theoretical Force at 0.6 MPa (6 bar, 87 psi), Advance Stroke: 483N
  • Moving Mass: 1115g
  • Product Weight: 2904g
  • Alternative Connections: Refer to product drawing
  • Type of Mounting: With through-hole
  • Pneumatic Connection: G1/8
  • Material Cover: Wrought aluminium alloy
  • Material Seals: HNBR
  • Material Housing: Wrought aluminium alloy
  • Material Piston Rod: High-alloy stainless steel

Accessories



Product

Manufacturer Material ID -
DGSL-25-30-EA
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85389099
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
32151705
Festo

Availability Available to order

£45.01
