6904722

Field-Wireable Connector, Male Connector M12 × 1, Straight

Manufacturer's No: BMSWS8151-8.5     Manufacturer: Turck Banner
Field-Wireable Connector, Male Connector M12 × 1, Straight

Availability On Request

POA
  • Field-Wireable Male Connector M12 × 1, Straight
  • Voltage: 125 V
  • For PROFIBUS-DP applications
  • Data rate: Up to 12 Mbps
  • Shielding: Iris spring connection
  • B-coding, Metal housing
  • Screw-clamp terminal, 5-pin
  • M18 × 1 metric screw-in thread
  • Cable diameter: 6.0 - 8.5 mm


Product

Manufacturer Material ID -
BMSWS8151-8.5
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85366990990
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39121402

Technical Specification

Ambient temperature -
-25 Degrees celsius
Connectable conductor cross section fine-strand with cable end sleeve -
0.14 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.14 Square millimetre
Connectable conductor cross section multi-wired -
0.14 Square millimetre
Connectable conductor cross section solid-core -
0.14 Square millimetre
Degree of protection (IP), mounted -
IP67
Diameter connector -
8.5 Millimetre
Housing material -
Zinc
Material of contact surface -
Gold
Rated current In -
4 Ampere
Rated voltage -
125 Volt
Type of electric connection -
Other
Type of housing -
Straight
Turck Banner

Availability On Request

POA
