QSPLKG20-1/2-U Cartridge

Manufacturer's No: QSPLKG20-1/2-U     Manufacturer: Festo
QSPLKG20-1/2-U Cartridge

Availability Available to order

£4.24
  • Cartridge model: QSPLKG20-1/2-U
  • Polymer version, grey, L-shape design with mounting pin
  • Cartridge size: 20 mm for tubing O.D. 1/2 in
  • Package quantity: 10 pieces
  • Operating pressure range: -0.095 MPa to 1 MPa (-0.95 bar to 10 bar, -13.775 psi to 145 psi)
  • Design: Push-pull principle, suitable for maritime use
  • Operating medium: Compressed air to ISO 8573-1:2010
  • Lubricated operation possible
  • Corrosion resistance class: 1 (Low corrosion stress)
  • LABS (PWIS) conformity: VDMA24364-B1/B2-L

Read more

  • Ambient temperature range: -5°C to 60°C (23°F to 140°F)
  • Product weight: 17 g
  • Material: Housing - PA-reinforced, Release ring - POM, Tubing seal - NBR, Tubing clamp component - High-alloy stainless steel
  • RoHS-compliant materials
  • Mounting: Mounting pin
  • Pneumatic connections: Port 1 - Cartridge 20 mm, Port 2 - For tubing O.D. 1/2"
  • Colour of release ring: Grey


Product

Manufacturer Material ID -
QSPLKG20-1/2-U
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
8536 5019
Country of Origin -
JP
UNSPSC -
41111926
