1PH81351DG022BH1

SIMOTICS M compact asynchronous motor 2000 r/min, 21.5 kW, 103 Nm 2650 r/min, 26.0 kW, 94 Nm 2800 r/min, 26.0 kW, 89 Nm forced ven

Manufacturer's No: 1PH8135-1DG02-2BH1     Manufacturer: Siemens
SIMOTICS M compact asynchronous motor 2000 r/min, 21.5 kW, 103 Nm 2650 r/min, 26.0 kW, 94 Nm 2800 r/min, 26.0 kW, 89 Nm forced ventilation; degree of protection IP65 direction of air flow DE--> NDE;

Availability On Request

POA
  • SIMOTICS M Compact Asynchronous Motor
  • Speed and Power:
    • 2000 r/min, 21.5 kW, 103 Nm
    • 2650 r/min, 26.0 kW, 94 Nm
    • 2800 r/min, 26.0 kW, 89 Nm
  • Forced Ventilation
  • Degree of Protection:
    • IP65
    • Direction of Air Flow: DE --> NDE
    • IP55
  • Incremental Encoder:
    • 22-bit with commutation position (encoder IC22DQ)
    • DRIVE-CLiQ interface
  • Type of Construction: IM B5 (IM V1, IM V3)
  • Shaft with Feather Key
    • Half-key balancing
  • Bearing Version: Standard with fixed bearing
  • Offer Number: SMR-139-2013
  • Customer-specific Motor


Product

Manufacturer Material ID -
1PH8135-1DG02-2BH1
Net Weight -
139.00kg

Additional Product Information

Commodity Code -
85015230
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: N
RoHs Compliance -
Yes
UNSPSC -
26101114

Technical Specification

Model -
UN
Voltage type -
UN
Rated current -
- Ampere
Rated voltage -
- Volt
Number of phases -
-
Energy efficiency class -
UN
Construction type -
UN
Number of poles -
-
Rated frequency -
- Hertz
Operation temperature -
- Degrees celsius
Rated rotational speed at rated frequency -
- Per minute
Rated performance at rated frequency -
- Kilowatt
Degree of protection (IP) -
UN
Duty cycle -
UN
Frame size acc. IEC -
- Millimetre
Full-load efficiency -
- Percentage
Starting current ratio -
-
Starting torque ratio -
-
Breakdown torque ratio -
-
Voltage anti-condensation heater -
- Volt
Output power anti-condensation heater -
- Watt
Intrinsic safety (IS) -
UN
Cooling method -
UN
Shaft end type -
UN
Vacuum pressure impregnation (VPI) -
UN
Degree of protection (NEMA) -
UN
Bearing -
UN
Insulation class acc. IEC -
UN
Nominal torque -
- Newtonmetre
Power factor -
-

Availability On Request

POA
