1SDA101386R1

XT7S M 800 Ekip Touch Meas.LSI 800 3p FF

Manufacturer's No: 1SDA101386R1     Manufacturer: ABB
XT7S M 800 Ekip Touch Meas.LSI 800 3p FF

Availability On Request

£6,734.38
  • Circuit Breaker Model: TMAX XT7S 800
  • Configuration: Fixed three-pole
  • Operating Mechanism: Stored energy and lever
  • Release Type: Solid-state
  • Front Terminals
  • Measurement Function: Ekip Touch Meas.LSI 800
  • Suitable for AC applications


Product

Manufacturer Material ID -
1SDA101386R1
Net Weight -
11.20kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
IT
UNSPSC -
39122330

Technical Specification

Rated short-circuit breaking capacity lcu at 400 V, 50 Hz -
50 kiloampere
Adjustment range short-term delayed short-circuit release -
480 Ampere
Adjustment range undelayed short-circuit release -
1200 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP20
Device construction -
Built-in device fixed built-in technique
Motor drive optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
3
Overload release current setting -
320 Ampere
Position of connection for main current circuit -
Front
Power loss -
24 Watt
Rated permanent current Iu -
800 Ampere
Rated voltage -
690 Volt
Type of control element -
Toggle
Type of electrical connection of main circuit -
Bolt connection
ABB

Availability On Request

£6,734.38
