2TLA020002R0200

JSHD4H2A 0.15m Three-position dual pushbutton

Manufacturer's No: 20-002-02     Manufacturer: ABB
JSHD4H2A 0.15m Three-position dual pushbutton

Availability On Request

£342.48
  • Model: JSHD4H2A
  • Type: Three-position dual pushbutton
  • Length of leads: 150mm
  • Mounting: External panel mounting with mounting holes up left
  • Function: Allows limited movement of the machine for troubleshooting, test running, and programming
  • Ideal for use when operator needs to be in dangerous area


Product

Manufacturer Material ID -
20-002-02
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85369095
Country of Origin -
SE
Minimum Order Quantity -
1
UNSPSC -
39122331

Technical Specification

Rated operation current Ie at AC12, 125 V -
- Ampere
Rated operation current Ie at AC12, 220 V -
- Ampere
Rated operation current Ie at AC12, 24 V -
- Ampere
Degree of protection (NEMA) -
UN
Degree of protection (IP) -
IP65
Performance level acc. EN ISO 13849-1 -
Level e
Cross-wire monitoring possible -
Degree of protection (IP rating) -
IP65
Number of contacts as change-over contact -
2
Number of contacts as normally closed contact -
0
Number of contacts as normally open contact -
0
Number of extra push buttons -
0
Performance level acc. to EN ISO 13849-1 -
Level e
Rated operation current Ie at DC-12, 24 V -
0.02 Ampere
Suitable for safety functions -
Type of electric connection -
Other
Type of switching contact -
Quick-break switch
