2091-1430/200-604

THR male header, 1.0 mm Ø solder pin, angled, black

Manufacturer's No: 2091-1430/200-604     Manufacturer: WAGO
THR male header, 1.0 mm Ø solder pin, angled, black

Availability Back Order

POA
  • THR male header
  • 1.0 mm diameter solder pin
  • Angled design
  • Pin spacing of 3.5 mm
  • 10-pole configuration
  • Color: black

Accessories

Coding Key Carrier, Suitable For 3.5 mm Pin Spacing Orange

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 2091-1610
Price £0.10
Back Order


Product

Manufacturer Material ID -
2091-1430/200-604
Net Weight -
0.38kg

Additional Product Information

Commodity Code -
85366990
Country of Origin -
DE
UNSPSC -
32151705

Technical Specification

Angle PCB/contact -
0°/180° (horizontal)
Connector model -
Free connector
Diameter connection pin -
1 Millimetre
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
3.6 Millimetre
Material insulation body -
Thermoplastic
Modular spacing connections -
3.5 Millimetre
Modular spacing contacts -
3.5 Millimetre
Number of plug-in contact rows -
1
Number of poles -
10
Operating temperature -
-60 Degrees celsius
Pollution degree -
2
Rated current In -
10 Ampere
Rated surge voltage -
2.5 Kilovolt
Rated voltage -
160 Volt
Suitable for PCB thickness -
2 Millimetre
Type of banding -
None
Type of PCB fastening -
Connecting contact
