2092-1404/200-000

Male header, straight solder pins 4-pole Pin spacing 5 mm / 0.197 in light gray

Manufacturer's No: 2092-1404/200-000     Manufacturer: WAGO
Male header, straight solder pins 4-pole Pin spacing 5 mm / 0.197 in light gray

Availability Back Order

POA
  • THR male header
  • 1.4 mm Ø solder pin
  • Straight pins
  • Pin spacing: 5 mm
  • 4-pole configuration
  • Color: Light gray

Accessories

Coding Key Carrier, Orange

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 2092-1610
Price £0.10
Back Order


Product

Manufacturer Material ID -
2092-1404/200-000
Net Weight -
0.58kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
DE
UNSPSC -
30265802

Technical Specification

Colour housing -
Other
Operation temperature -
-60 Degrees celsius
Angle PCB/contact -
90° (upwards vertical)
Connector model -
Free connector
Contact type -
Pin
Diameter connection pin -
1.4 Millimetre
Housing colour -
Other
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
3.6 Millimetre
Material insulation body -
Thermoplastic
Material of contact surface -
Tin
Modular spacing connections -
5 Millimetre
Modular spacing contacts -
5 Millimetre
Number of plug-in contact rows -
1
Number of poles -
4
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
16 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
320 Volt
Suitable for PCB thickness -
2 Millimetre
Type of banding -
None
Type of connection -
Flexible PCB-connector
Type of electric connection -
Soldering connection
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact

Availability Back Order

POA
