232-149/005-000

Female connector for rail-mount terminal blocks, 0.6 x 1 mm pins, straight, Pin spacing 5 mm, 19-pol

Manufacturer's No: 232-149/005-000     Manufacturer: WAGO
Female connector for rail-mount terminal blocks, 0.6 x 1 mm pins, straight, Pin spacing 5 mm, 19-pol

Availability Back Order

POA
  • Female connector for rail-mount terminal blocks
  • 19-pole with 0.6 x 1 mm straight pins
  • Pin spacing of 5 mm
  • Color: gray

Accessories



Product

Manufacturer Material ID -
232-149/005-000
Net Weight -
0.27kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Drill hole distance centrically -
- Millimetre
Connectable conductor cross section solid-core -
- Square millimetre
Connectable conductor cross section fine-strand with cable end sleeve -
- Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
- Square millimetre
Connectable conductor cross section multi-wired -
- Square millimetre
Length -
11.6 Millimetre
Operation temperature -
105 Degrees celsius
Number of clamp positions per pole -
1
Width/grid dimension -
5 Millimetre
Height at lowest possible mounting height -
18.25 Millimetre
Connection position -
Above
Colour -
Grey
Depth -
11.6 Millimetre
Height -
18.25 Millimetre
Inflammability class of insulation material acc. with UL94 -
V0
Material insulation body -
Thermoplastic
Mounting method -
Other
Number of poles -
19
Operating temperature -
-60 Degrees celsius
Rated current In -
12 Ampere
Rated voltage -
320 Volt
Type of electrical connection 1 -
Spring clamp connection
Type of electrical connection 2 -
Spring clamp connection
Width -
5 Millimetre

Availability Back Order

POA
