251-310

PCB Terminal Block, 1 mm² Pin Spacing 3.5 mm 10-Pole White

Manufacturer's No: 251-310     Manufacturer: WAGO
PCB Terminal Block, 1 mm² Pin Spacing 3.5 mm 10-Pole White

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.00

£1.70
  • PCB Terminal Block
    • 10-Pole
    • Pin Spacing: 3.5 mm
    • Wire Size: 1 mm²
    • Color: White
    • Connection Type: Push Wire & Fit Clamp


Product

Manufacturer Material ID -
251-310
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
39269097
Country of Origin -
CH
Minimum Order Quantity -
30
UNSPSC -
39121410

Technical Specification

Diameter connection pin -
- Millimetre
Connectable conductor cross section fine-strand with cable end sleeve -
- Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
- Square millimetre
Connectable conductor cross section multi-wired -
- Square millimetre
Degree of protection (IP), mounted -
UN
Height -
12.3 Millimetre
Colour housing -
White
Rated voltage -
320 Volt
Operation temperature -
-60 Degrees celsius
Type of fastening -
Solder
Inflammability class of insulation material acc. with UL94 -
V0
Number of levels -
1
Rated surge voltage -
4 Kilovolt
Over voltage category -
III
Pollution degree -
2
Connection type conductor -
Plug clamp connection
Connection type PCB -
Soldering connection
Length pin -
3.6 Millimetre
Material connection surface -
Tin
Modular spacing connections -
3.5 Millimetre
Type of banding -
None
Connectable conductor cross section solid-core -
0.5 Square millimetre
Material insulation body -
Thermoplastic
Angle PCB/conductor connection -
0°/180° (horizontal)
Type of PCB fastening -
Connecting contact
Rated current In -
2 Ampere
Number of electrical connections -
10
