254-849

Stackable PCB terminal block, 2.5 mm², Pin spacing 5/5.08 mm, black

Manufacturer's No: 254-849     Manufacturer: WAGO
Stackable PCB terminal block, 2.5 mm², Pin spacing 5/5.08 mm, black

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.50

POA
  • Stackable PCB terminal block
  • Pin spacing: 5/5.08 mm
  • 1-pole configuration
  • PUSH WIRE® technology
  • Wire size capacity: 2.5 mm²
  • Color: black


Product

Manufacturer Material ID -
254-849
Net Weight -
0.60kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
PL
UNSPSC -
39121410

Technical Specification

Diameter connection pin -
- Millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
- Square millimetre
Connectable conductor cross section multi-wired -
- Square millimetre
Degree of protection (IP), mounted -
UN
Colour housing -
Black
Operation temperature -
-60 Degrees celsius
Angle PCB/conductor connection -
45°/135° (downwards inclined)
Connectable conductor cross section fine-strand with cable end sleeve -
0.5 Square millimetre
Connectable conductor cross section solid-core -
0.5 Square millimetre
Connection type conductor -
Plug clamp connection
Connection type PCB -
Soldering connection
Height -
15.7 Millimetre
Housing colour -
Black
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
4 Millimetre
Material connection surface -
Tin
Material insulation body -
Thermoplastic
Modular spacing connections -
5 Millimetre
Number of electrical connections -
1
Number of levels -
1
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
24 Ampere
Rated surge voltage -
4 Kilovolt
Rated voltage -
320 Volt
Type of banding -
None
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact
