2606-1104/020-004

PCB terminal block with high-voltage symbol, black for 5 terminal blocks, yellow

Manufacturer's No: 2606-1104/020-004     Manufacturer: WAGO
PCB terminal block with high-voltage symbol, black for 5 terminal blocks, yellow

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.00

£5.42
  • PCB terminal block with high-voltage symbol
  • Color: Black
  • Quantity: 5 terminal blocks
  • Color: Yellow
  • Type: Lever
  • Pin spacing: 7.5 mm
  • Number of poles: 4
  • Connection type: Push-in CAGE CLAMP
  • Wire size: 6.00 mm
  • Color: Black


Product

Manufacturer Material ID -
2606-1104/020-004
Net Weight -

Additional Product Information

Commodity Code -
85365005
Country of Origin -
DE
UNSPSC -
39121410

Technical Specification

Diameter connection pin -
- Millimetre
Degree of protection (IP), mounted -
UN
Colour housing -
Black
Operation temperature -
-60 Degrees celsius
Height -
24 Millimetre
Housing colour -
Black
Rated voltage -
1000 Volt
Operating temperature -
-60 Degrees celsius
Type of fastening -
Solder
Inflammability class of insulation material acc. with UL94 -
V0
Number of levels -
1
Rated surge voltage -
8 Kilovolt
Over voltage category -
III
Pollution degree -
2
Connection type conductor -
Spring clamp connection
Connection type PCB -
Soldering connection
Length pin -
4 Millimetre
Material connection surface -
Tin
Modular spacing connections -
7.5 Millimetre
Type of banding -
None
Connectable conductor cross section solid-core -
0.2 Square millimetre
Connectable conductor cross section fine-strand with cable end sleeve -
0.25 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.2 Square millimetre
Connectable conductor cross section multi-wired -
0.2 Square millimetre
Material insulation body -
Thermoplastic
Angle PCB/conductor connection -
0°/180° (horizontal)
Type of PCB fastening -
Connecting contact
Rated current In -
41 Ampere
Number of electrical connections -
4

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.00

£5.42
