2626-1103/020-004

PCB terminal block, 6 mm, Pin spacing 7.5 mm, 3-pole, Push-in CAGE CLAMP, 6, 00 mm, black

Manufacturer's No: 2626-1103/020-004     Manufacturer: WAGO
PCB terminal block, 6 mm, Pin spacing 7.5 mm, 3-pole, Push-in CAGE CLAMP, 6, 00 mm, black

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£2.93
  • PCB terminal block
  • 3-pole
  • Pin spacing: 7.5 mm
  • Wire size: 6.00 mm²
  • Push-in CAGE CLAMP®
  • Color: black

Accessories

Ferrule, Sleeve For 1 mm / Awg 18 Insulated Red

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-263
Price £0.09
Back Order

Ferrule, Sleeve For 1.5 mm / Awg 16 Insulated Black

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-264
Price £0.09
Back Order

Ferrule, Sleeve For 2.5 mm / Awg 14 Insulated Blue

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-266
Price £0.09
Back Order

Ferrule; Sleeve for 4 mm / AWG 12; insulated; electro-tin plated; electrolytic copper; gastight crimped; acc. to DIN 46228, Part 4/09.90

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-267
Price £0.09
Back Order

Ferrule, Sleeve For 6 mm / Awg 10 Insulated Yellow

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-208
Price £0.16
In Stock

Ferrule, Sleeve For 6 mm / Awg 10 Uninsulated

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 216-108
Price £0.04
Back Order


Product

Manufacturer Material ID -
2626-1103/020-004
Net Weight -
1.15kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
PL
UNSPSC -
39121402

Technical Specification

Diameter connection pin -
- Millimetre
Degree of protection (IP), mounted -
UN
Colour housing -
Black
Operation temperature -
-60 Degrees celsius
Angle PCB/conductor connection -
0°/180° (horizontal)
Connectable conductor cross section fine-strand with cable end sleeve -
0.25 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.2 Square millimetre
Connectable conductor cross section multi-wired -
0.2 Square millimetre
Connectable conductor cross section solid-core -
0.2 Square millimetre
Connection type conductor -
Spring clamp connection
Connection type PCB -
Soldering connection
Height -
19.6 Millimetre
Housing colour -
Black
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
4 Millimetre
Material connection surface -
Tin
Material insulation body -
Thermoplastic
Modular spacing connections -
7.5 Millimetre
Number of electrical connections -
3
Number of levels -
1
Operating temperature -
-60 Degrees celsius
Over voltage category -
III
Pollution degree -
2
Rated current In -
48 Ampere
Rated surge voltage -
8 Kilovolt
Rated voltage -
1000 Volt
Type of banding -
None
Type of fastening -
Solder
Type of PCB fastening -
Connecting contact

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£2.93
