2626-3101/000-016

PCB terminal block, 6 mm², Pin spacing 7.5 mm, green-yellow

Manufacturer's No: 2626-3101/000-016     Manufacturer: WAGO
PCB terminal block, 6 mm², Pin spacing 7.5 mm, green-yellow

Availability On Request

Once added to the cart, you can split this pack for a charge of £16.50

POA
  • PCB terminal block
  • 1-pole
  • Pin spacing: 7.5 mm
  • Wire size: 6.00 mm²
  • Connection type: Push-in CAGE CLAMP®
  • Color: Green-yellow


Product

Manufacturer Material ID -
2626-3101/000-016
Net Weight -
0.97kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
PL
UNSPSC -
39121410

Technical Specification

Housing colour -
Green/yellow
Type of fastening -
Solder
Over voltage category -
III
Angle PCB/conductor connection -
90° (upwards vertical)
Connectable conductor cross section fine-strand with cable end sleeve -
0.25 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.2 Square millimetre
Connectable conductor cross section multi-wired -
0.2 Square millimetre
Connectable conductor cross section solid-core -
0.2 Square millimetre
Connection type conductor -
Spring clamp connection
Connection type PCB -
Soldering connection
Height -
24.2 Millimetre
Inflammability class of insulation material acc. with UL94 -
V0
Length pin -
4 Millimetre
Material connection surface -
Tin
Material insulation body -
Thermoplastic
Modular spacing connections -
7.5 Millimetre
Number of electrical connections -
1
Number of levels -
1
Operating temperature -
-60 Degrees celsius
Pollution degree -
2
Rated current In -
48 Ampere
Rated surge voltage -
8 Kilovolt
Rated voltage -
1000 Volt
Type of banding -
None
Type of PCB fastening -
Connecting contact
