294-4035

Power supply connector without ground contact without snap-in mounting feet white

Manufacturer's No: 294-4035     Manufacturer: WAGO
Power supply connector without ground contact without snap-in mounting feet white

Availability Back Order

Once added to the cart, you can split this pack for a charge of £16.00

£1.37
  • Lighting connector with push-button design
  • External connector without ground contact
  • 5-pole connector with DA+, DA-, L, PE, N pins
  • Lighting side designed for solid conductors
  • Installation side compatible with all conductor types up to 2.5 mm²
  • Maximum surrounding air temperature of 85°C (T85)
  • White color connector

Accessories

Strain Relief Plate, With Secured Clamp 3- To 5-Pole

Once added to the cart, you can split this pack for a charge of £16.00

Product Code - 294-364
Price £0.38
Back Order


Product

Manufacturer Material ID -
294-4035
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85365005
Country of Origin -
CH
UNSPSC -
39121410

Technical Specification

Drill hole distance centrically -
- Millimetre
Length -
27.3 Millimetre
Operation temperature -
125 Degrees celsius
Width/grid dimension -
50 Millimetre
Height at lowest possible mounting height -
17 Millimetre
Connection position -
Sideways
Colour -
White
Connectable conductor cross section fine-strand with cable end sleeve -
0.5 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
0.5 Square millimetre
Connectable conductor cross section multi-wired -
0.5 Square millimetre
Connectable conductor cross section solid-core -
0.5 Square millimetre
Depth -
17 Millimetre
Halogen free -
Height -
27.3 Millimetre
Inflammability class of insulation material acc. with UL94 -
V0
Material insulation body -
Thermoplastic
Mounting method -
Other
Number of clamp positions per pole -
2
Number of poles -
5
Operating temperature -
125 Degrees celsius
Rated current In -
24 Ampere
Rated voltage -
500 Volt
Type of electrical connection 1 -
Spring clamp connection
Type of electrical connection 2 -
Plug clamp connection
Width -
50 Millimetre
