Contactor relay railway, 2 NO + 1 NC 125 V DC, 0.7 ... 1.25* US, with integrated suppressor diode, Size S00, screw terminal installation on standard mounting rail optimized (20G), suitable for PLC out

3RH21311KG400LA4

Contactor relay railway, 2 NO + 1 NC 125 V DC, 0.7 ... 1.25* US, with integrated suppressor diode, Size S00, screw terminal installation on standard mounting rail optimized (20G), suitable for PLC out

Produced by Siemens

Availability Back Order

Price - £61.74
Contactor relay railway, 2 NO + 1 NC 125 V DC, 0.7 ... 1.25* US, with integrated suppressor diode, Size S00, screw terminal installation on standard mounting rail optimized (20G), suitable for PLC outputs
Product
Manufacturer Material ID -
3RH2131-1KG40-0LA4
Net Weight -
0.30kg
Additional Product Information
Commodity Code -
85364900
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
39121529
Technical Specification
Rated control supply voltage Us at DC -
125 Volt
Number of auxiliary contacts as normally open contact -
3
Rated operation current Ie, 400 V -
3 Ampere
Rated control supply voltage at DC -
125 Volt
