3RH29112XB220MA0

Auxiliary switch 11 U, on the front, 2 NO + 2 NC Current path 1 NO, 1 NC, 1 NC, 1 NO for 3RH and 3RT spring-type terminal 53/54, 6

Manufacturer's No: 3RH2911-2XB22-0MA0     Manufacturer: Siemens

Availability Back Order

£22.91
  • Auxiliary switch located on the front
  • Configuration: 2 Normally Open (NO) + 2 Normally Closed (NC)
  • Rated voltage: 11 V
  • Compatible with contactors 3RT2 and contactor relays 3RH2
  • Current path: 1 NO, 1 NC, 1 NC (lagging), 1 NO (leading)
  • Spring-loaded terminal for easy installation
Question and Answer (Q&A video)
Instructional video
Presentation video
Question and Answer (Q&A video)
Product video
Presentation video
Product video
Instructional video


Product

Manufacturer Material ID -
3RH2911-2XB22-0MA0
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
CZ
RoHs Compliance -
Yes
UNSPSC -
39121522

Technical Specification

Lamp holder -
None
Model -
Clip-on
Lamp cap/base -
None
Mounting method -
Other
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
2
Number of contacts as normally open contact -
2
Number of fault-signal switches -
0
Rated operation current Ie at AC-15, 230 V -
6 Ampere
Type of electric connection -
Spring clamp connection

Availability Back Order

£22.91
