3RK13010BB130AA4

F-DS1E-X for ET 200S Fail-safe DOL starter Setting range 2.4...8 A Mechanical switching Electronic p

Manufacturer's No: 3RK1301-0BB13-0AA4     Manufacturer: Siemens
F-DS1E-X for ET 200S Fail-safe DOL starter Setting range 2.4...8 A Mechanical switching Electronic p

Availability Back Order

POA
  • Model: F-DS1E-X for ET 200S Fail-safe DOL starter
  • Setting Range: 2.4 to 8 A
  • Switching Type: Mechanical
  • Electronic Protection: AC-3, up to 3 kW / 400 V
  • Expandable for Brake Control Module and 2DI Module
  • Circuit Breaker Signaling Parameterizable

Follow-up article



Product

Manufacturer Material ID -
3RK1301-0BB13-0AA4
Net Weight -
1.70kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
DE
Export Control Regulations -
EAR99 / N
Minimum Order Quantity -
1
UNSPSC -
39121529

Technical Specification

Number of command positions -
-
Number of auxiliary contacts as normally open contact -
-
Number of auxiliary contacts as normally closed contact -
-
Rated operation current Ie -
- Ampere
Number of indicator lights -
-
Rated control supply voltage Us at AC 50HZ -
- Volt
Rated control supply voltage Us at AC 60HZ -
- Volt
Type of electrical connection for auxiliary- and control current circuit -
UN
Rated operation power at AC-3, 230 V, 3-phase -
- Kilowatt
Rated power, 460 V, 60 Hz, 3-phase -
- Kilowatt
Rated power, 575 V, 60 Hz, 3-phase -
- Kilowatt
Ambient temperature, upper operating limit -
- Degrees celsius
Rated conditional short-circuit current, type 2, 400 V -
- Ampere
Rated conditional short-circuit current, type 2, 230 V -
- Ampere
Rated conditional short-circuit current, type 1, 480 Y/277 V -
- Ampere
Rated conditional short-circuit current, type 1, 600 Y/347 V -
- Ampere
Degree of protection (NEMA) -
UN
Rated control supply voltage Us at DC -
21.6 Volt
Degree of protection (IP) -
IP20
Coordination class according to IEC 60947-4-3 -
Class 2
Degree of protection (IP rating) -
IP20
Depth -
150 Millimetre
Height -
290 Millimetre
Kind of motor starter -
Direct starter
Overload release current setting -
2.4 Ampere
Rated control supply voltage at DC -
21.6 Volt
Rated operation current at AC-3, 400 V -
8 Ampere
Rated operation power at AC-3, 400 V -
3 Kilowatt
Release class -
Other
Type of electrical connection of main circuit -
Screw connection
Voltage type for actuating -
DC
Width -
65 Millimetre
With short-circuit release -
