3SE22836GA53

Hinge switch Molded-plastic enclosure with aluminum hinge 3xNC, Slow-action contacts for 40 mm profi

Manufacturer's No: 3SE2283-6GA53     Manufacturer: Siemens
Hinge switch Molded-plastic enclosure with aluminum hinge 3xNC, Slow-action contacts for 40 mm profi

Availability Back Order

£171.36
  • Molded-plastic enclosure with aluminum hinge
  • Hinge switch with 3xNC, Slow-action contacts
  • Suitable for 40 mm profiles
  • Supplied with additional hinge and fixing material
  • Cable entry: 2 x M20 x 1.5
  • Actuating angle: 8°

Accessories



Product

Manufacturer Material ID -
3SE2283-6GA53
Net Weight -
0.42kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Rated operation current Ie at DC-13, 230 V -
- Ampere
Rated operation current Ie at AC-15, 24 V -
- Ampere
Rated operation current Ie at DC-13, 125 V -
- Ampere
Degree of protection (NEMA) -
UN
Material housing -
Plastic
Degree of protection (IP) -
IP65
Type of interface -
None
Coating housing -
Other
Type of switching contact -
Slow-action switch
Type of electric connection -
Cable entry metrical
Type of control element -
Other
Alignment of the control element -
Roller cam straight
Ambient temperature during operating -
-25 Degrees celsius
Construction type housing -
Special construction
Degree of protection (IP rating) -
IP65
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Forced opening -
Height of sensor -
36 Millimetre
Housing material -
Plastic
Interface type -
None
Length of sensor -
92 Millimetre
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
3
Number of contacts as normally open contact -
0
Number of safety auxiliary contacts -
3
Rated operation current Ie at AC-15, 125 V -
4.2 Ampere
Rated operation current Ie at AC-15, 230 V -
2 Ampere
Rated operation current Ie at DC-13, 24 V -
1 Ampere
Suitable for safety functions -
Switching function -
Slow-action switch
Type of interface for safety communication -
None
Width sensor -
111.5 Millimetre

Availability Back Order

£171.36
