3SE52123RV40

Safety position switch with separate actuator, metal enclosure, 31 mm

Manufacturer's No: 3SE5212-3RV40     Manufacturer: Siemens
Safety position switch with separate actuator, metal enclosure, 31 mm

Availability On Request

£67.56
  • Safety position switch with separate actuator
  • Metal enclosure with dimensions 31 mm
  • Plastic head with 1x M20x1.5 thread
  • Slow-action contacts: 1 NO + 1 NC
  • 2x LED indicators (yellow/green) for 230 V AC
  • 5 directions of approach
  • Matching separate actuator model: 3SE5000-0AV0./-0AW. (must be ordered separately)

Accessories

Product video
Question and Answer (Q&A video)
Product video
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3SE5212-3RV40
Net Weight -
0.24kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
RoHs Compliance -
Yes
UNSPSC -
39122216

Technical Specification

Rated operation current Ie at DC-13, 230 V -
- Ampere
Rated operation current Ie at AC-15, 125 V -
- Ampere
Rated operation current Ie at AC-15, 24 V -
- Ampere
Rated operation current Ie at DC-13, 125 V -
- Ampere
Rated operation current Ie at DC-13, 24 V -
- Ampere
Material housing -
Metal
Type of switching contact -
Slow-action switch
Type of electric connection -
Cable entry metrical
Degree of protection (IP) -
IP66/IP67
Type of interface -
None
Alignment of the control element -
Roller cam straight
Ambient temperature during operating -
-25 Degrees celsius
Coating housing -
Lacquered
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP66/IP67
Degree of protection (NEMA) -
12
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Forced opening -
Height of sensor -
33 Millimetre
Housing material -
Metal
Interface type -
None
Length of sensor -
104 Millimetre
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Number of safety auxiliary contacts -
1
Rated operation current Ie at AC-15, 230 V -
4 Ampere
Suitable for safety functions -
Switching function -
Slow-action switch
Type of control element -
None
Type of interface for safety communication -
None
Width sensor -
31 Millimetre
With status indication -
