3SE52140CC051AC5

Position switch Metal enclosure according to EN 50047, 31 mm 1 NO/1 NC quick action contacts with M1

Manufacturer's No: 3SE5214-0CC05-1AC5     Manufacturer: Siemens
Position switch Metal enclosure according to EN 50047, 31 mm 1 NO/1 NC quick action contacts with M1

Availability On Request

£44.35
  • Position switch with metal enclosure according to EN 50047
  • 31 mm size
  • 1 Normally Open (NO) and 1 Normally Closed (NC) quick action contacts
  • Equipped with an M12 plug
  • 5-pole pin assignment:
    • Pin 1: 21
    • Pin 2: 22
    • Pin 3: 13
    • Pin 4: 14
    • Pin 5: PE (Protective Earth)
  • Maximum rating: 125 V, 4 A
  • Features a plunger operation

Accessories

Component part

Product video
Question and Answer (Q&A video)
Product video
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3SE5214-0CC05-1AC5
Net Weight -
0.19kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
DE
Export Control Regulations -
N / N
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Rated operation current Ie at AC-15, 230 V -
- Ampere
Rated operation current Ie at DC-13, 230 V -
- Ampere
Diameter sensor -
- Millimetre
Degree of protection (NEMA) -
UN
Material housing -
Metal
Type of electric connection -
Plug-in connection M12
Degree of protection (IP) -
IP66/IP67
Type of interface -
None
Type of control element -
Plunger
Alignment of the control element -
Roller cam straight
Ambient temperature during operating -
-25 Degrees celsius
Coating housing -
Lacquered
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP66/IP67
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Forced opening -
Height of sensor -
33 Millimetre
Housing material -
Metal
Interface type -
None
Length of sensor -
75.7 Millimetre
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Number of safety auxiliary contacts -
1
Rated operation current Ie at AC-15, 125 V -
4 Ampere
Rated operation current Ie at AC-15, 24 V -
4 Ampere
Rated operation current Ie at DC-13, 125 V -
0.55 Ampere
Rated operation current Ie at DC-13, 24 V -
3 Ampere
Suitable for safety functions -
Switching function -
Quick-break switch
Type of interface for safety communication -
None
Width sensor -
31 Millimetre

Availability On Request

£44.35
