3SU11502BL603LA0

Toggle switch, illuminable, 22 mm, round, metal, high gloss, white, 2x1 NO+1 NC

Manufacturer's No: 3SU1150-2BL60-3LA0     Manufacturer: Siemens
Toggle switch, illuminable, 22 mm, round, metal, high gloss, white, 2x1 NO+1 NC

View 3D

Availability Back Order

£31.47
  • Illuminable 22mm round metal selector switch
  • Shiny white finish
  • Short with 3 switch positions: I-O-II
  • Latching mechanism
  • Actuating angle of 2x45 degrees
  • Positions at 10:30h, 12h, and 13:30h
  • Comes with holder
  • Configuration: 2 normally open (NO) + 1 normally closed (NC) contacts
  • Equipped with spring-type terminals

Accessories

Component part

Question and Answer (Q&A video)
Question and Answer (Q&A video)
Question and Answer (Q&A video)
Instructional video
Presentation video
Question and Answer (Q&A video)
Presentation video
Instructional video


Product

Manufacturer Material ID -
3SU1150-2BL60-3LA0
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85365080
Country of Origin -
CZ
Export Control Regulations -
AL: N / ECCN: N
RoHs Compliance -
Yes
UNSPSC -
39122216

Technical Specification

Degree of protection (IP) -
IP67/IP69K
Colour front ring -
Other
Colour button -
White
Degree of protection (IP rating) -
IP67/IP69K
Degree of protection (NEMA) -
Other
Height opening -
28.8 Millimetre
Hole diameter -
22.3 Millimetre
Material front ring -
Other
Number of contacts as change-over contact -
0
Number of contacts as normally closed contact -
2
Number of contacts as normally open contact -
2
Number of switch positions -
3
Suitable for illumination -
Supply voltage -
5 Volt
Type of control element -
Toggle
Type of electric connection -
Spring clamp connection
Width opening -
32.3 Millimetre
With front ring -

Availability Back Order

£31.47
