3VA11125ED120AA0

Circuit Breaker 3Va1 Iec Frame 160 Breaking Capacity Class M Icu=55Ka @ 240V 1-Pole

Manufacturer's No: 3VA1112-5ED12-0AA0     Manufacturer: Siemens
Circuit Breaker 3Va1 Iec Frame 160 Breaking Capacity Class M Icu=55Ka @ 240V 1-Pole

Availability On Request

£179.00
  • Circuit Breaker: 3VA1 IEC Frame 160
  • Breaking Capacity: Class M, Icu = 55 kA @ 240 V
  • Configuration: 1-pole
  • Line Protection: TM210, FTFM
  • Rated Current: In = 125 A
  • Overload Protection: Ir = 125 A
  • Short-Circuit Protection: Permanently set at 10 x In
  • Includes Nut Keeper Kit

Accessories

Question and Answer (Q&A video)
Product video
Instructional video
Question and Answer (Q&A video)
Instructional video
Product video


Product

Manufacturer Material ID -
3VA1112-5ED12-0AA0
Net Weight -
0.35kg

Additional Product Information

Commodity Code -
85362090
Country of Origin -
CZ
RoHs Compliance -
Yes
UNSPSC -
39121601

Technical Specification

Adjustment range short-term delayed short-circuit release -
- Ampere
Degree of protection (IP) -
IP40
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz -
6 kiloampere
Adjustment range undelayed short-circuit release -
1250 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
1
Overload release current setting -
125 Ampere
Position of connection for main current circuit -
Front
Power loss -
9.37 Watt
Rated permanent current Iu -
125 Ampere
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz -
6 kiloampere
Rated voltage -
415 Volt
Suitable for DIN rail (top hat rail) mounting -
Type of control element -
Rocker lever
Type of electrical connection of main circuit -
Screw connection

Availability On Request

£179.00
