3VA61501MS310AA0

Circuit breaker 3VA6 UL frame 150 3-pole, starter protection ETU310M, I, In=50 A

Manufacturer's No: 3VA6150-1MS31-0AA0     Manufacturer: Siemens
Circuit breaker 3VA6 UL frame 150 3-pole, starter protection ETU310M, I, In=50 A

Availability On Request

£433.69
  • Circuit breaker model: 3VA6 UL frame 150
  • Configuration: 3-pole
  • Starter protection: ETU310M
  • Rated current: In=50A
  • Short-circuit protection: Ii=3...15 x In
  • Overload protection: Not included

Accessories

Question and Answer (Q&A video)
Question and Answer (Q&A video)


Product

Manufacturer Material ID -
3VA6150-1MS31-0AA0
Net Weight -
2.50kg

Additional Product Information

Commodity Code -
85362010
Country of Origin -
CZ
RoHs Compliance -
Yes
UNSPSC -
39121601

Technical Specification

Overload release current setting -
- Ampere
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz -
- kiloampere
Adjustment range short-term delayed short-circuit release -
- Ampere
Degree of protection (IP) -
IP40
Position of connection for main current circuit -
Other
Type of electrical connection of main circuit -
Other
Adjustment range undelayed short-circuit release -
150 Ampere
Complete device with protection unit -
Degree of protection (IP rating) -
IP40
Device construction -
Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional -
Motor drive optional -
Number of auxiliary contacts as change-over contact -
0
Number of auxiliary contacts as normally closed contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of poles -
3
Power loss -
3.8 Watt
Rated permanent current Iu -
50 Ampere
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz -
110 kiloampere
Rated voltage -
690 Volt
Type of control element -
Rocker lever

Availability On Request

£433.69
